ZhuoMao ZM-R5830 Touch Screen BGA Rework Station Hot Air 3 Zones For Laptop Motherboard Chip Repair 4500W
Zhuomao BGA Rework Station has widely applied to repair different ranges of electronics products. From low level chipsets repair to high level chipsets repair.
The main user is repairing shops and factory to provide the after-sales service and PCBA PCB’S rework.
First Parameters:
1 |
Total power |
4800W |
2 |
Top hot air heater |
800W |
3 |
2nd hot air heater |
1200W |
4 |
Bottom IR preheater |
2700W |
5 |
Voltage |
210V-240V |
6 |
PCB board positioning |
V-groove, PCB support can be adjusted in any direction with smart universal fixture |
7 |
Temp. control |
(K Sensor) closed loop, independent heating, precision within ±3 degree |
8 |
Machine parts material |
Highly sensitive temperature control module+Touch screen (Taiwan)+Delta PLC |
9 |
PCB board size |
Max 410×370mm Min 20×20 mm |
10 |
Dimensions |
635×600×560 mm |
11 |
Machine body net weight |
40kg |
Second Features:
1 |
Adopt linear slide which makes X, Y, Z axis all can do micro adjust or rapid positioning, with high precision, easy to operate; |
2 |
High definition touch screen (Taiwan) , PCL control, can save many groups profiles, password protection function, with instant temperature curve analysis function; |
3 |
3 independent heating areas. The 1st and 2nd are hot-air heaters, the 3rd is IR preheating. |
4 |
Offer all sizes of hot-air nozzle, can rotate 360°;With magnet, easy to install and change, customized size is available; |
5 |
K-type thermocouple (closed loop), heat independently, temperature precision is within ± 3degree; |
6 |
V-groove PCB support can be adjusted in any direction with external universal fixture, suitable for all kinds of BGA repair; |
7 |
Powerful cross-flow fan rapidly cool the PCB board to improve efficiency; Also built-in vacuum pump and external vacuum suction pen, pick up the chips easily; |
8 |
After finishing desoldering & soldering, there is an alarming and alarming in advance; |
9 |
CE certificate, with emergency stop and automatic power-off protection device when abnormal accident happens;with a double temp protection. |
Free gifts for Black Friday:
5 bottles soldering balls(25k leaded type 0.2mm 0.3mm 0.4mm 0.5mm 0.6mm)
4 pcs PS4 directly heat stencils
1 piece 90mm reballing station
